Broadcast Graphics API: Publish, Version, Roll Back

LIGR publishes a graphic in a fixed order: create the theme and the graphic once, push the bundle, publish a graphic version, publish a theme version that pins it, then inspect and activate that theme version. This guide walks through that sequence twice, once with the ligr-graphic CLI (in beta, like the routes it calls) and once over the broadcast graphics API with curl. Then it covers versions, rollback and native Rive graphics. Every command and response below is copied from the Push and publish page, the Publish a theme version guide, and the Rive Command line and Import through REST pages.

It is written for developers, integrators and broadcast engineers who publish graphics from a script rather than the dashboard.

What you are publishing

A code graphic is a graphic you write yourself in HTML, CSS and JavaScript. The LIGR overlay loads it in a transparent frame over the video, sends it live match data, and tells it when to show and when to hide. It runs beside the Rive graphics in the same theme, and operators drive it from the same control room.

The overlay is a GPU-accelerated Chromium browser. Any rendering library that runs in a browser works inside your graphic, including Three.js, PixiJS, Rive, Lottie and GSAP.

Publishing works on the theme tree. These are the objects you touch, as the Concepts page defines them:

Nothing reaches air by being pushed. A push changes the working version. A publish freezes it. A theme version pins frozen graphic versions. Only activation changes what an overlay loads, on its next page load.

Before you start

• A write key. In the dashboard, open the account menu and select Developers → API keys → Create API key. Only admins and owners see Developers. Theme and code graphic routes sit under the themes resource, so the key needs themes:write, which includes themes:read. A read key on a write route returns 403 with INSUFFICIENT_SCOPE. See Authentication.
• A theme your organisation owns. You create it yourself. An organisation can own up to five themes.
• A built bundle. A bundle is the folder of static files the overlay loads, usually dist/. Use relative paths only, keep the <body> background transparent and make no network call at runtime. One file can be up to 5 MiB and one bundle up to 10 MiB. See Bundle rules.
• A manifest. Keep it in graphic.json next to your source. Over REST it is the stateMachine field. See The manifest.

Test before you push. npx ligr-graphic dev runs a local harness that needs no API key and sends the same message order as the LIGR overlay. The Test and troubleshoot page has the checklist to run before a broadcast.

The sequence at a glance

Both routes run the same calls. The CLI folds the upload steps into one command.

Route 1: the ligr-graphic CLI

ligr-graphic runs the REST calls for you. Set LIGR_API_KEY in your shell and replace 203 with your theme id. npx ligr-graphic theme list prints the themes your organisation owns. The Quick start covers scaffolding a new graphic.

npx ligr-graphic theme create --name "My Theme" --sports football

npx ligr-graphic create --theme 203 --name "Scorebug" --sports football

npx ligr-graphic push

npx ligr-graphic publish --theme-version

npx ligr-graphic theme inspect --theme 203 --version 12
npx ligr-graphic theme activate --theme 203 --version 12

Route 2: the REST API

Send the key as Authorization: Bearer <api key>. The base URL is https://api.ligr.live/rest. Create the theme and the graphic once, then upload and publish each revision. A full push of a one-file graphic is four requests.

Create the theme and the graphic

curl -X POST 'https://api.ligr.live/rest/v2/themes' \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{ "name": "My Theme", "sports": ["football"],
        "variables": [{ "id": "accent", "name": "accent", "type": "string", "defaultValue": "#ff0000" }] }'

{ "id": 203, "name": "My Theme", "activeVersion": null, "versions": [], "graphics": [] }

curl -X POST 'https://api.ligr.live/rest/v2/themes/203/code-graphics' \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{ "name": "Scorebug", "sports": ["football"] }'

{
  "graphicId": "e5515527-238e-44cb-9567-b65902218d47",
  "id": 1761,
  "name": "Scorebug",
  "type": "code",
  "version": 0,
  "sports": ["football"],
  "publishedVersions": [],
  "lock": null
}

Upload the files and record the bundle

curl -X POST "https://api.ligr.live/rest/v2/themes/203/code-graphics/$GRAPHIC_ID/uploads" \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{ "files": [
    { "name": "index.html", "contentType": "text/html" },
    { "name": "assets/app.js", "contentType": "application/javascript" }
  ] }'

{
  "uploadSessionId": "823d14c6-ef4e-4d72-932e-20d8ed422e3c",
  "uploads": [
    { "name": "index.html", "url": "https://…?X-Amz-Signature=…", "method": "PUT", "expiresInSeconds": 600 },
    { "name": "assets/app.js", "url": "https://…?X-Amz-Signature=…", "method": "PUT", "expiresInSeconds": 600 }
  ]
}

curl -X PUT "$UPLOAD_URL" \
  -H 'Content-Type: text/html' \
  --data-binary @dist/index.html

curl -X PUT "https://api.ligr.live/rest/v2/themes/203/code-graphics/$GRAPHIC_ID/bundle" \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{
    "uploadSessionId": "823d14c6-ef4e-4d72-932e-20d8ed422e3c",
    "files": [
      { "name": "index.html", "mime": "text/html", "size": 1240, "hash": "sha256:6f1c…" },
      { "name": "assets/app.js", "mime": "application/javascript", "size": 8300, "hash": "sha256:9b02…" }
    ],
    "stateMachine": { "schemaVersion": 1, "runtime": { "engine": "iframe-html", "entryFile": "index.html", "width": 1920, "height": 1080, "exitDurationMs": 800 }, "controlVariables": [], "userExpressions": [] }
  }'

The answer is the working copy of the graphic, with its assets and its publishedVersions. Nothing is published yet.

Publish and activate

curl -X POST "https://api.ligr.live/rest/v2/themes/203/code-graphics/$GRAPHIC_ID/versions" \
  -H "Authorization: Bearer $LIGR_API_KEY"

{ "version": 3 }

curl -X POST 'https://api.ligr.live/rest/v2/themes/203/versions' \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{ "activate": false }'

{ "version": 12, "activeVersion": 11 }

curl -X PUT 'https://api.ligr.live/rest/v2/themes/203/active-version' \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{ "version": 12 }'

{ "activeVersion": 12 }

Reload the preview overlay to load the selected version, and check it before you reload a broadcast browser source.

Why graphics versioning matters

Versions keep editing, releasing and going on air apart.

• Published versions are immutable. A later push changes only the working copy. A published graphic version keeps the files it was published with.
• A theme version is frozen. It pins a set of published graphic versions. Inspecting version 12 shows the same selections regardless of later graphic publications.
• Activation is a separate request. Publishing a theme version changes nothing on air. The active version changes only when you call PUT …/active-version or theme activate.
• Overlays load on page load. An overlay loads the active theme version when its page loads. Existing overlay pages keep their loaded version until reloaded.

That last point matters on match day. Activation does not change a graphic already loaded on a live browser source. The change lands when that source reloads, so you choose the moment.

Pin the versions you want

A theme version publish pins every graphic you list at the version you give, and every graphic you do not list at its latest published version. A graphic with no published version is left out. A theme version can pin published versions only.

So if one graphic is not ready, you can still publish the others and hold that one at a known good version. From the guide:

curl -X POST 'https://api.ligr.live/rest/v2/themes/203/versions' \
  -H "Authorization: Bearer $LIGR_API_KEY" \
  -H 'Content-Type: application/json' \
  -d '{
    "graphics": [
      { "graphicId": "c1e2a9d0-5b7e-4f60-9c3a-2d1f0e8b7a64", "version": 5 }
    ]
  }'

In that example the lower third is pinned at version 5 and the scorebug at its latest, version 3. The active version is still 11. Nothing changed on air.

Rolling back a bad graphic mid-season

The documented rollback works at the theme version level. You activate an older theme snapshot that already holds the graphic versions you trust.

npx ligr-graphic theme inspect --theme 203 --version 11
npx ligr-graphic theme activate --theme 203 --version 11

Two effects to plan for. Because activation is shared, the rollback applies to every competition using that theme. And presets for graphics absent from the selected snapshot are hidden. They return if you activate a snapshot containing those graphics.

The Rive route, briefly

Native Rive graphics are a separate path. A native Rive graphic stores exact .riv runtime bytes, one artboard, one state machine and LIGR configuration, and LIGR renders it through the native Rive runtime inside an isolated browser frame. It does not use the Graphics SDK or the ligr.gfx.v1 protocol.

Here the upload can be a source project. LIGR stores a .riv unchanged, and extracts and compiles a .rev or a complete RML project ZIP into a runtime. Check GET /v2/themes/{themeId}/rive-graphics/capabilities before each import. The CLI does the whole import in one command, as Command line shows:

npx ligr-graphic rive import ./continental-scorebug.zip \
  --theme 203 --name "Continental scorebug"

Over REST, Import through REST uploads the file, prepares it, polls until it is ready, and creates the working graphic. The page defines a small api shell helper first. Its publish step:

GRAPHIC_VERSION=$(api POST "v2/themes/$THEME_ID/rive-graphics/$GRAPHIC_ID/versions" | jq -er '.version')

THEME_VERSION=$(api POST "v2/themes/$THEME_ID/versions" --data "$(jq -n \
  --arg graphicId "$GRAPHIC_ID" --argjson version "$GRAPHIC_VERSION" \
  '{graphics: [{graphicId: $graphicId, version: $version}], activate: false}')" | jq -er '.version')

api PUT "v2/themes/$THEME_ID/active-version" \
  --data "$(jq -n --argjson version "$THEME_VERSION" '{version: $version}')" | jq

These are three separate mutations. Activation changes what new overlay page loads will render.
